Multi-band RTK GNSS receiver with centimeter precision
Emlid produces affordable GNSS modules and receivers suitable for RTK and PPK. Highly accurate Reach receivers can work with signals from all the main satellite systems: GPS, GLONASS. They also accept data from BeiDou, QZSS, Galileo.
Meet the new Emlid GNSS receiver the Reach RS2+
For our MALÅ GPR products: The upgraded Reach RS2+ now has a built in LTE modem with 2G/3G fallback and global coverage and also features a range of design improvements to enhance usability in the field.
GPS for surveying, mapping and navigation. Get the most out of a survey by pairing your MALÅ GPR with the Emlid Reach RS2+.
Locate buried objects and artifacts with accuracy. Pairing the RS2+ and MALÅ GPR gives your data a unique position for each pulse, letting you identify and mark the position and depth of buried metallic and non-metallic objects.
Gets a fix in seconds
Reach RS2+ gets a fixed solution in just seconds and maintains robust performance even in challenging conditions. Centimeter accuracy can be achieved on distances up to 60 km in RTK, and 100 km in PPK mode.
PPP support
RINEX raw data logs are compatible with PPP services so you can now get centimeter-precise results in any place on Earth. Process RINEX files in an online service and get position with absolute accuracy.
Application areas
The ABEM Terrameter Log 300 is a capable borehole logging tool for recording resistivity, IP, SP and temperature. In general, it can be used in any application where greater resolution and/or direct measurement of resistivity is required at depth. This might be to help identify thin layers or improve the quality of inversion results by providing a sample of true resistivity values to the software. Commonly it is used for groundwater studies to help better define the geological formations and assess water quality by estimating the TDS (total dissolved solids).
Features
Surveying with ReachView 3
The most user-friendly software for data collection that is available both for Android and iOS. Supports thousands of coordinate systems and is translated into multiple languages. With ReachView 3, you can collect and stake out points and control all the features of Reach receivers, such as setting up a base station, logging RINEX data, and configuring NMEA output.
Point collection: save points, and export data to CSV
Record each position as a point with centimeter precise coordinates. Export projects and open them in GIS or CAD software like AutoCAD, ArcGIS, QGIS, and others.
Coordinate systems based on:
WGS84, NAD83, GDA2020, and others
Stakeout: find point’s position on the ground
Stakeout is used to find exact physical locations of points. They can be collected in ReachView or imported from other CAD or GIS software.
Logging in RINEX: record raw data, position, and base correction logs
Record raw data, position and base correction logs. Point collection and recording of RAW data are independent processes and can be used simultaneously. ReachView has a simple and intuitive interface for logging configuration and control.
EMLID provide their version of RTKLib for PPK. It’s free and can be downloaded from the document section.
16 GB storage
160+ days of logging at 1 Hz
PPP for OPUS
RINEX raw data logs are compatible with PPP services so you can now get centimeter-precise results in any place on Earth. Process RINEX files in an online service and get position with absolute accuracy.
Built-in LTE modem (new)
Reach RS2+ features a power-efficient LTE modem with 2G/3G fallback and global coverage. Now corrections can be accessed or broadcasted over NTRIP independently, without relying on an Internet connection on your phone.
22 hours on 1 charge
Up to 22 hours of autonomous work when logging data and up to 16 hours as a 3G rover, even in cold weather—no more need to carry spare batteries with you. Reach RS2+ can charge from a USB wall charger or a power bank over USB-C.
Pinpoint physical locations
Get centimeter precision on large scale 3D GPR mapping with RS2+ and MALÅ MIRA HDR
With MIRAsoft HDR acquisition software, you will experience a modern and easy-to-use interface with integrated navigation aids, that speed up your surveys even further. Connecting the RS2+ with MIRAsoft HDR lets you track the performance and data collection in detail, helps to maintain the correct speed and course, shows real-time slice views and real-time GPS positioning.
IP67
RS2+ is waterproof up to 1 m depth. All connectors are completely sealed and protected from water and dust with silicone plugs.
-20ºС to +65ºС
Extensively tested in conditions that simulate coldest winters and hottest summers, just like all MALÅ GPR products.
Polycarbonate body
Polycarbonate, an extremely durable material that is used in bulletproof glass, makes Reach RS2+ impact-resistant.
